IAM Federation is currently behind the experimental.iam_federation feature flag. Ask your Hoop admin to enable it for your organization before configuring the GCP side.

Before you start, you need a working Hoop connection to attach federation to. Federation layers per-user cloud credentials onto an existing connection — it doesn’t create one for you.

Create the connection first — for BigQuery, follow Connect to BigQuery. Verify it works end-to-end with hoop connect <name> before continuing.
Complete the GCP IAM setup below to mint the admin service account.
Wire policy + credentials onto the connection with hoop admin federation set.
Validate end-to-end with hoop admin federation test.

The rest of this page is step 2. The CLI reference covers steps 3 and 4.

What this gives you

With IAM Federation enabled, Hoop stops sharing a single Google service-account key with every user. Instead, when Alice runs hoop connect my-bq, the gateway:

Reads the connection’s federation policy (identity template, project id, fallback rules).
Asks Google’s iamcredentials API to mint an OAuth access token as Alice’s principal, using the admin service account it has stored for your organization.
Hands that short-lived token to the agent. Every subsequent bq query shows up in Cloud Logging attributed to Alice — not to the shared admin service account.

For this to work, two things must be true on the GCP side:

The admin service account must be allowed to impersonate each user’s target principal. This is the roles/iam.serviceAccountTokenCreator grant.
Each target principal must have whatever data-plane roles it needs (e.g. roles/bigquery.user for BigQuery).

This page is about the first part: granting Token Creator. The second part is standard IAM you probably already know how to do.

Prerequisites

# Use your real project id.
export PROJECT_ID="my-proj"

# Pick a name for the admin service account Hoop will hold the key to.
export ADMIN_SA="hoop-admin"
export ADMIN_EMAIL="${ADMIN_SA}@${PROJECT_ID}.iam.gserviceaccount.com"

gcloud config set project "$PROJECT_ID"

Enable the API Hoop calls into:

gcloud services enable iamcredentials.googleapis.com

Without this, every federated session fails at the GenerateAccessToken call with PERMISSION_DENIED: IAM Service Account Credentials API has not been used.

Step 1 — Create the admin service account

The admin SA is the only identity Hoop’s gateway authenticates with. It never reads user data directly; it only mints tokens for the user principals.

gcloud iam service-accounts create "$ADMIN_SA" \
  --display-name="Hoop Federation Admin"

# Export the JSON key — this is what you'll paste into Hoop.
gcloud iam service-accounts keys create ./hoop-admin-sa.json \
  --iam-account="$ADMIN_EMAIL"

You’ll feed hoop-admin-sa.json to:

hoop admin federation set my-bq \
    --file federation.yaml \
    --credentials-file ./hoop-admin-sa.json

After Hoop has accepted the key, delete the local file — Hoop encrypts it at rest and the gateway is now the only place it needs to live.

Step 2 — Grant Token Creator (pick one pattern)

You have two patterns depending on how granular you want your GCP audit trail.

Pattern A — Per-user grant (recommended)

Create one GCP service account per Hoop user, then let the admin SA impersonate only those specific accounts. Cleanest audit trail, smallest blast radius if the admin key ever leaks.

# Repeat per user — example: alice
USER_SA_NAME="alice"
USER_EMAIL="${USER_SA_NAME}@${PROJECT_ID}.iam.gserviceaccount.com"

# Create the per-user service account
gcloud iam service-accounts create "$USER_SA_NAME" \
  --display-name="Hoop user: alice"

# Let the admin SA impersonate this user-SA
gcloud iam service-accounts add-iam-policy-binding "$USER_EMAIL" \
  --member="serviceAccount:${ADMIN_EMAIL}" \
  --role="roles/iam.serviceAccountTokenCreator"

# Grant the user-SA the data access it actually needs (BigQuery in this example)
gcloud projects add-iam-policy-binding "$PROJECT_ID" \
  --member="serviceAccount:${USER_EMAIL}" \
  --role="roles/bigquery.user"

gcloud projects add-iam-policy-binding "$PROJECT_ID" \
  --member="serviceAccount:${USER_EMAIL}" \
  --role="roles/bigquery.dataViewer"

Pair this with a federation policy that maps each Hoop user to their SA via a template:

# federation.yaml
builtin_provider: gcp_iam
identity_target_template: "{user.email_local}@my-proj.iam.gserviceaccount.com"
fallback_policy: deny
token_ttl_seconds: 3600
extra_config:
  project_id: my-proj

The {user.email_local} placeholder expands to the part of the Hoop user’s email before the @ (e.g. alice@example.com → alice). The SA names you created in gcloud must match this expansion. If you’d rather namespace Hoop-managed SAs with a prefix (e.g. hoop-alice), include the prefix both in your gcloud iam service-accounts create command and in the template: "hoop-{user.email_local}@...".

GCP service-account names must be 6–30 lowercase letters, digits, and hyphens; they must start with a letter and end with a letter or digit. If your users have dots or plus signs in their email local parts (first.last@example.com), {user.email_local} will render an illegal SA name and federation will fail with a clear preflight error. Use a shorter handle attribute, or use Pattern B with a literal shared SA.

Pattern B — Project-wide grant (simpler)

Grant the admin SA serviceAccountTokenCreator at the project level once. It can then impersonate any SA in the project. Faster to set up, but a compromised admin key reaches every SA in the project.

gcloud projects add-iam-policy-binding "$PROJECT_ID" \
  --member="serviceAccount:${ADMIN_EMAIL}" \
  --role="roles/iam.serviceAccountTokenCreator"

You still need to create the target service accounts and grant them their data-plane roles — only the impersonation grant is collapsed.

Step 3 — Verify the grant before saving in Hoop

Before pasting the admin key into Hoop, prove the impersonation actually works from a regular shell. Hoop does exactly this call on every session-open, so a green light here means a green light in Hoop.

# Auth as the admin SA
gcloud auth activate-service-account --key-file=./hoop-admin-sa.json

# Try to mint a token AS one of your target user-SAs
gcloud auth print-access-token \
  --impersonate-service-account="alice@${PROJECT_ID}.iam.gserviceaccount.com" \
  --scopes=https://www.googleapis.com/auth/cloud-platform

What you’ll see:

Output	Meaning	Fix
A long `ya29.…` token	All grants correct. Ready to feed `hoop-admin-sa.json` to Hoop.	—
`403: The caller does not have permission`	Admin SA is missing `roles/iam.serviceAccountTokenCreator` on the target.	Re-run step 2.
`404: Service account … does not exist`	Typo in the target email or the user-SA was never created.	Re-check `gcloud iam service-accounts list`.
`400: Invalid form of account ID`	The identity template would produce an illegal SA name (dots, plus signs, too short).	Adjust the template — see the warning under Pattern A.

Step 4 — Test end-to-end from Hoop

Once the gcloud check passes, do the same test from inside Hoop. This both verifies impersonation and runs a real SELECT 1 through the agent — catching agent-side problems too.

hoop admin federation test \
    --connection my-bq \
    --user-email alice@example.com \
    --credentials-file ./hoop-admin-sa.json

A green result looks like:

Connection:             my-bq
Status:                 SUCCESS
Resolved Principal:     alice@my-proj.iam.gserviceaccount.com
Admin Principal:        hoop-admin@my-proj.iam.gserviceaccount.com
Token Expires At:       2026-05-25T18:00:00Z
Injected Env Var Keys:  CLOUDSDK_CORE_PROJECT, HOOP_FEDERATED_PRINCIPAL, HOOP_GCP_ACCESS_TOKEN, HOOP_GCP_TOKEN_EXPIRES_AT
Superseded Static Envs: GOOGLE_APPLICATION_CREDENTIALS
Probe Status:           success

Probe Output:
+---+
| f0_ |
+---+
| 1 |
+---+

Superseded Static Envs: GOOGLE_APPLICATION_CREDENTIALS is the signal that the legacy SA key file on the connection is being correctly ignored in favor of the federated token. You don’t need to manually remove it from the connection — Hoop strips it server-side on every federated session.

What you’ll see in GCP audit logs

After federation is wired up, every BigQuery query produced through Hoop generates two correlated log entries:

# 1. The impersonation event (in Cloud Logging, IAM service)
protoPayload.serviceName: iamcredentials.googleapis.com
protoPayload.methodName: GenerateAccessToken
protoPayload.authenticationInfo.principalEmail: hoop-admin@my-proj.iam.gserviceaccount.com
protoPayload.request.name: projects/-/serviceAccounts/alice@my-proj.iam.gserviceaccount.com

# 2. The actual BigQuery job (in Cloud Logging, BigQuery service)
protoPayload.serviceName: bigquery.googleapis.com
protoPayload.methodName: jobservice.insert
protoPayload.authenticationInfo.principalEmail: alice@my-proj.iam.gserviceaccount.com
protoPayload.authenticationInfo.serviceAccountDelegationInfo:
  - firstPartyPrincipal:
      principalEmail: hoop-admin@my-proj.iam.gserviceaccount.com

The serviceAccountDelegationInfo chain is what gives you the full picture: who ran the query (the user-SA Alice was mapped to) and through whom (the Hoop admin SA). That delegation chain is the audit story IAM federation buys you. The two log streams live in different audit log tiers, which matters for how you enable and find them:

Log type	Service	Event	Default?
Admin Activity	`iamcredentials.googleapis.com`	`GenerateAccessToken` — proves impersonation happened	On by default, free
Data Access	`bigquery.googleapis.com`	`jobservice.insert`, `jobservice.jobcompleted` — proves the query ran as Alice	Off by default, billed per GiB

Enable Data Access logs first

BigQuery Data Access logs are disabled by default. If you set up federation and only see GenerateAccessToken events (Hoop minted the token) but not the query itself, this is why. Enable them once at the project level:

# Pull the current IAM policy, add the auditConfigs block, push it back.
gcloud projects get-iam-policy "$PROJECT_ID" --format=json > /tmp/policy.json

# Edit /tmp/policy.json — add this entry to the top-level "auditConfigs"
# array (create the array if it doesn't exist):
#   {
#     "service": "bigquery.googleapis.com",
#     "auditLogConfigs": [
#       { "logType": "ADMIN_READ" },
#       { "logType": "DATA_READ" },
#       { "logType": "DATA_WRITE" }
#     ]
#   }

gcloud projects set-iam-policy "$PROJECT_ID" /tmp/policy.json

After this every BigQuery job (including Hoop-sourced ones) generates a protoPayload.serviceName: bigquery.googleapis.com entry. Data Access logs are billed at standard Cloud Logging rates — typically negligible for query metadata but worth scoping by sink filter if your project runs millions of jobs/day.

Quick verification with `gcloud logging read`

Right after a hoop connect my-bq + bq query session as Alice, fetch the two correlated entries:

# 1. Hoop's impersonation events from the last hour
gcloud logging read '
  protoPayload.serviceName="iamcredentials.googleapis.com"
  AND protoPayload.methodName="GenerateAccessToken"
  AND protoPayload.authenticationInfo.principalEmail="hoop-admin@my-proj.iam.gserviceaccount.com"
  AND timestamp >= "'"$(date -u -v-1H +%Y-%m-%dT%H:%M:%SZ)"'"
' --limit=20 --format=json --project="$PROJECT_ID"

# 2. Alice's BigQuery activity from the last hour
gcloud logging read '
  protoPayload.serviceName="bigquery.googleapis.com"
  AND protoPayload.authenticationInfo.principalEmail="alice@my-proj.iam.gserviceaccount.com"
  AND timestamp >= "'"$(date -u -v-1H +%Y-%m-%dT%H:%M:%SZ)"'"
' --limit=20 --format=json --project="$PROJECT_ID"

The -v-1H argument is the BSD date syntax used on macOS. On Linux use --date '1 hour ago' instead: timestamp >= "$(date -u --date='1 hour ago' +%Y-%m-%dT%H:%M:%SZ)".

Browse in Cloud Logging Explorer

Console → Logging → Logs Explorer. The canonical filter for “everything that ever went through Hoop federation, regardless of which user” pivots on the delegation chain:

protoPayload.serviceName="bigquery.googleapis.com"
protoPayload.authenticationInfo.serviceAccountDelegationInfo.firstPartyPrincipal.principalEmail="hoop-admin@my-proj.iam.gserviceaccount.com"

Save it as a custom view — it’s the query you’ll come back to whenever you need to prove “every BigQuery query in this project went through Hoop” for a compliance audit. Conversely, queries where principalEmail is the admin SA itself (with no delegation chain) are the ones that bypassed federation — alert on those if you want to enforce “all access goes through Hoop”.

Long-term audit: sink to BigQuery

For real history and analytics, route the audit logs into a BigQuery dataset and query them with SQL. This is the production-grade pattern for compliance reporting.

# 1. Create the destination dataset
bq --project_id="$PROJECT_ID" mk --dataset \
  --description="Hoop federation audit sink" \
  audit_logs

# 2. Create the sink with a filter scoped to Hoop's admin SA
gcloud logging sinks create hoop-federation-audit \
  bigquery.googleapis.com/projects/"$PROJECT_ID"/datasets/audit_logs \
  --log-filter='
    (protoPayload.serviceName="bigquery.googleapis.com"
     OR protoPayload.serviceName="iamcredentials.googleapis.com")
    AND protoPayload.authenticationInfo.serviceAccountDelegationInfo.firstPartyPrincipal.principalEmail="hoop-admin@my-proj.iam.gserviceaccount.com"
  ' \
  --project="$PROJECT_ID"

# 3. Grant the sink's auto-generated writer SA permission to write to the dataset
SINK_WRITER=$(gcloud logging sinks describe hoop-federation-audit \
  --project="$PROJECT_ID" --format='value(writerIdentity)')
bq add-iam-policy-binding --member="$SINK_WRITER" \
  --role="roles/bigquery.dataEditor" "$PROJECT_ID:audit_logs"

After ~15 minutes the sink starts populating daily-partitioned tables. Query Alice’s last 24h of Hoop-sourced queries with regular SQL:

SELECT
  timestamp,
  protoPayload.authenticationInfo.principalEmail AS resolved_principal,
  protoPayload.serviceData.jobQueryResponse.job.jobConfiguration.query.query AS query_text
FROM `my-proj.audit_logs.cloudaudit_googleapis_com_data_access_*`
WHERE protoPayload.serviceName = 'bigquery.googleapis.com'
  AND protoPayload.authenticationInfo.principalEmail = 'alice@my-proj.iam.gserviceaccount.com'
  AND timestamp > TIMESTAMP_SUB(CURRENT_TIMESTAMP(), INTERVAL 24 HOUR)
ORDER BY timestamp DESC;

The _* wildcard covers Cloud Logging’s daily-partitioned sink tables (cloudaudit_googleapis_com_data_access_20260528, ..._20260529, etc.).

Common pitfalls

I see GenerateAccessToken events but no BigQuery query entries

BigQuery Data Access logs are off by default. The GenerateAccessToken event lives in the always-on Admin Activity tier, but the actual query (jobservice.insert) lives in Data Access — which has to be opted into. Enable it project-wide with the auditConfigs snippet under Enable Data Access logs first, then re-run a query. New entries appear in Cloud Logging within seconds.

403 IAM_SERVICE_ACCOUNT_TOKEN_CREATOR after granting the role

GCP IAM grants are eventually consistent. Wait 1–2 minutes after running add-iam-policy-binding, then retry. If it still fails, double-check the grant is on the target SA (the per-user one), not on the admin SA:

gcloud iam service-accounts get-iam-policy \
    alice@${PROJECT_ID}.iam.gserviceaccount.com

You should see your admin SA listed with roles/iam.serviceAccountTokenCreator.

BigQuery returns Access Denied even though impersonation works

Impersonation produces the token, but the target principal also needs BigQuery roles. Verify with:

gcloud projects get-iam-policy "$PROJECT_ID" \
  --flatten="bindings[].members" \
  --filter="bindings.members:alice@${PROJECT_ID}.iam.gserviceaccount.com" \
  --format="table(bindings.role)"

You should see roles/bigquery.user and roles/bigquery.dataViewer (or finer-grained equivalents).

warning: both HOOP_GCP_ACCESS_TOKEN and GOOGLE_APPLICATION_CREDENTIALS are set

Harmless on older gateway versions. On current versions the gateway strips GOOGLE_APPLICATION_CREDENTIALS from the federated session, so this warning never fires from a normal session — if you see it now, your agent is being driven by an older gateway that hasn’t been updated yet.

Identity template renders to an empty principal

fallback_policy: deny aborts the session with a clear error. Pick fallback_policy: readonly with a readonly_principal if you want a safe-by-default identity for users who don’t yet have their own SA.

Documentation Index

​What this gives you

​Prerequisites

​Step 1 — Create the admin service account

​Step 2 — Grant Token Creator (pick one pattern)

​Pattern A — Per-user grant (recommended)

​Pattern B — Project-wide grant (simpler)

​Step 3 — Verify the grant before saving in Hoop

​Step 4 — Test end-to-end from Hoop

​What you’ll see in GCP audit logs

​Enable Data Access logs first

​Quick verification with gcloud logging read

​Browse in Cloud Logging Explorer

​Long-term audit: sink to BigQuery

​Common pitfalls

What this gives you

Prerequisites

Step 1 — Create the admin service account

Step 2 — Grant Token Creator (pick one pattern)

Pattern A — Per-user grant (recommended)

Pattern B — Project-wide grant (simpler)

Step 3 — Verify the grant before saving in Hoop

Step 4 — Test end-to-end from Hoop

What you’ll see in GCP audit logs

Enable Data Access logs first

Quick verification with `gcloud logging read`

Browse in Cloud Logging Explorer

Long-term audit: sink to BigQuery

Common pitfalls
